Product materialbyPTFE, carbon, graphite, glass fiber, polymer organic matter, etc., and the steel back are tightly bonded
Product featuresGood elasticity and shock absorption performance
Application scenarioWidely used in chemical industry, food industry, Textile industry and automobile hinges
| H | 0.48±0.02 |
| project | unit | Material model | ||
| MYB401 | MYB402 | |||
| Maximum bearing capacityP | dynamic load | MPa | 80 | 80 |
| quiescent load | MPa | 100 | 100 | |
| Maximum linear velocityV(grease lubrication) | m/s | 1 | 1 | |
| highestPVvalue | N/mm2·m/s | 1.6 | 1.6 | |
| friction factor | - | ≤0.2 | ≤0.2 | |
| compression deformation 23℃/100MPa/1h | mm | ≤0.04 | ≤0.04 | |
| volume resistivity | Ώcm | ≤105 | ＞1012 | |
| Working temperature | long term | ℃ | -200 ～ +260 | -200 ～ +260 |
| short-term | ≤280 | ≤280 | ||
| Thermal conductivity | W(m·k) | 25 | 25 | |
| thermal expansivity | K-1 | 18X10-6 | 18X10-6 | |
